Total Dynamic Head (TDH) Calculations and Pump Impeller Curve Sizing

Total Dynamic Head (TDH) is the sum of all resistances a pump must overcome to move water from the pond through the filtration system and back again. It is the single most important variable in system design because it defines the operating point where the pump curve and the system curve intersect. TDH is often misestimated as the static lift from pump to waterfall, but the static lift is only the starting point: friction losses through pipe, fittings, valves, and filter media can easily double or triple the required head. Underestimating TDH leaves the pump operating far to the left of its Best Efficiency Point, dramatically reducing flow and wasting energy; overestimating it leads to an oversized pump that creates excessive velocity, increases energy consumption, and may even damage filter media.

This page works through the practical hydraulics of TDH: how to calculate static head, friction head (using the Hazen-Williams or Darcy-Weisbach equations), and equipment head loss; how to interpret pump impeller curves; and how to match the pump’s performance to the system’s requirements. The guidance here is not a substitute for a full engineering analysis — pipe diameter, material, run length, fitting count, filter type, and the pump’s actual operating point all shift the numbers. Every design decision must be checked against the specific system rather than a rule of thumb. We provide the framework; your job is to apply it to your specific pond and equipment.

Test Your TDH & Pump Sizing Knowledge

Work through ten scenario-based questions covering static head, friction loss, pump curve interpretation, and system matching. Each answer includes the reasoning behind it.
